Gastite®

Gastite® FlashShield™ T325-5-3 Maxitrol Regulator, 1 in Pipe, 550000 Btu/hr Capacity, 600000 Btu/hr Load, Domestic

TFT32553 MFG #: T325-5-3
Gastite® FlashShield™ T325-5-3 Maxitrol Regulator, 1 in Pipe, 550000 Btu/hr Capacity, 600000 Btu/hr Load, Domestic
  • Capacity: 550000 Btu/hr
  • Connection Type: NPT
  • Country of Origin: US
  • Domestic/Import: Domestic
  • Inlet Pressure Range: 0.5 to 2 psi
  • Load Capacity: 600000 Btu/hr
  • Manufacturer Name: Titeflex
  • Outlet Pressure Range: 8 in WC
  • Pipe Size: 1 in
  • Series: Maxitrol
Gastite® FlashShield™ Regulator, Series: Maxitrol, 1 in Pipe, 550000 Btu/hr, 0.5 to 2 psi Inlet Pressure, 8 in WC Outlet Pressure, 600000 Btu/hr, Natural, NPT, Domestic,
  • Features and More

Features

  • Designed for multi-poise mounting
  • Self-aligning valve with lever action for dead end regulator lockup
  • Durable, corrosion-resistant construction
  • High performance type for pounds to inches reduction
  • Precise regulation from pilot flows to full regulator capacity
  • CSA certified for up to 5 psi inlet pressure
  • Over-pressure protection device (OPD) to limit downstream pressure in case of regulator failure
  • For use in elevated pressure systems (in excess of 1/2 psi) to reduce pressure to standard appliance use levels

Standards/Approvals/Certifications

  • CSA Certified
