- Amperage Rating: 1.4 to 1.8 A
- Dimensions: 6-11/16 in W x 8-1/2 in H
- Flow Rate: 63 gpm
- Frequency Rating: 60 Hz
- Manufacturer Name: Grundfos
- Maximum Head: 14.11 ft
- Maximum Pressure: 145 psi
- Motor Speed: 3360 rpm
- Phase: 1 ph
- Power Rating: 203 W
- Series: UPS
- Voltage Rating: 115 VAC
The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid.
- Features and More
Features
- Ceramic shaft and radial bearings
- Carbon axial bearing
- Stainless steel rotor can and bearing plate
- Corrosion resistant impeller, composite, PES
- Cast iron pump housing
- 1 ph motor, no additional motor protection is required
Standards/Approvals/Certifications
- CSA Certified
- UL Listed
