Febco® 765EBV 765 N-Pattern Pressure Vacuum Breaker With Quarter Turn Ball Valve Shutoff, 1 in Nominal, NPT End Style, Quarter-Turn Ball Valve, Bronze Body, Vacuum Breaker, Import
Part #: FEBCO765EBV
MFG #: 765EBV
Series 765 Pressure Vacuum Breakers are designed to be installed to provide protection against back siphon age of toxic or non-toxic liquids. They feature a durable bronze body and a check valve and air opening port in one assembly. Maximum Working Pressure: 150 psi (10.3 bar).
Brand : Febco®
Backflow Type : Vacuum Breaker
Ball Valve/Gate Valve type : Quarter-Turn Ball Valve
Body Material : Bronze
Country of Origin : CN
Dimensions : 9 in L x 8-3/4 in H
Features
- Simple service procedures
- Designed for minimum head loss
- Internal parts easily serviceable in line from top of unit
- For use in health hazard cross connections and continuous pressure applications
- Durable bronze body construction
- Lightweight poppet seals air opening under minimum flow conditions
- Engineered plastic bonnet protect valve bodies from freeze damage
Application
- For protect against health hazard and non-health hazard backsiphonage conditions in industrial plants
- cooling towers laboratories
- laundries
- swimming pools and lawn sprinkler systems
Standards/Approvals/Certifications
- ANSI/ASME B1.20.1
- ASSE 1020
- CSA B64.1.2
- UPC Listed
- PROP65: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm.
